Cisco C9407R-96U-BNDL-1E Switch Price in Muscat, Oman

SKU: C9407R-96U-BNDL-1E

The Cisco Catalyst® 9400 Series switches are Cisco’s leading modular enterprise switching access platform built for security, IoT and cloud. The platform provides unparalleled investment protection with a chassis architecture that is capable of supporting up to 9Tbps of system bandwidth and unmatched power delivery for high density IEEE 802.3BT (60W PoE).

Add to compare
Add to wishlist
18 People watching this product now!

Description

C9407R-96U-BNDL-1E Specification
Total number of slots 7
Line-card slots 5
Supervisor engine slots 2
Dedicated supervisor engine slot numbers 3 and 4
Supervisor engine redundancy Yes
Supervisor engines supported C9400-SUP-1,

C9400-SUP-1XL, C9400-SUP-1XL-Y
Maximum PoE per slot 2880W
Maximum Bandwidth scalability per line-card slot Up to 480 Gbps on all slots
Number of power supply bays 8
AC input power Yes
Integrated PoE Yes
Power supplies supported 3200W AC, 2100W AC
Number of fan-tray bays 1
Location of 19-inch rack-mount Front
Dimensions (H x W x D) 17.41 x 17.30 x 16.30 in. (44.22 x 43.94 x 41.40cm)
Rack Units (RU) 10 RU
Chassis weight (with fan tray) 63.0 lb (28.58 kg)
Mounting 19-in rack compatible (19-in. rack and cable guide hardware included)
Regulatory compliance CE Marking
Safety ●  UL 60950-1

●  CAN/CSA-C222.2 No. 60950-1

●  EN 60950-1

●  IEC 60950-1

●  AS/NZS 60950.1

●  IEEE 802.3
EMC ●  47 CFR Part 15

●  CISPR22 Class A

●  KN 32 Class A

●  EN 300 386 V1.6.1

●  EN 55022 Class A

●  EN 55032 Class A

●  CISPR 32 Class A

●  EN61000-3-2

●  EN61000-3-3

●  ICES-003 Class A

●  TCVN 7189 Class A

●  V-3 Class A

●  CNS13438 Class A

●  CISPR24

●  EN 300 386

●  EN55024

●  TCVN 7317

●  KN35
Industry EMC, safety, and environmental standards ●  NEBS: Operating temperature: -5 to 55C

●  Relative Humidity: 10-93%

●  Operating Altitude: up to 1829 m (6000 ft) at 55C

●  ETSI 300-019 Requirements are covered under GR-63-CORE with some deviations.

●  SR-3580 NEBS level 3 (GR-63-CORE, to current issue, GR-1089-CORE, to current issue)

●  ETS 300 019-2-1, Class 1.2 Storage

●  ETS 300 019-2-2, Class 2.3 Transportation

●  ETS 300 019-2-3, Class 3.2 Stationary

●  EN50121-4

●  EN 300 386
ROHS compliance ROHS5
