Specifications
|
| Standard Model Numbers |
ST4000VX016 |
| SkyHawk™ Health Management Included |
Yes |
| Interface |
SATA 6Gb/s |
| Recording Technology |
CMR |
| Drive Design |
Air |
Features and Performance
|
| Drive Bays Supported |
Up to 16 |
| Cameras Supported |
Up to 64 |
| RV Sensors |
Yes |
| Max Sustained Transfer Rate OD (MB/s) |
180MB/s |
| Cache (MB) |
256MB |
Reliability/Data Integrity
|
| Tarnish Resistant |
Yes |
| Load/Unload Cycles |
600,000 |
| Nonrecoverable Read Errors Rate, Max |
1 per 10E14 |
| Power-On Hours per year |
8760 |
| Workload Rate Limit (WRL) 1 |
180 |
| Mean Time Between Failures (MTBF) (hours) |
1000000hr |
| Warranty, Limited (years) 2 |
3 |
| Rescue Data Recovery Services (years) 3 |
3 |
Power Management
|
| Startup Current, Typical (12V, A) |
1.8A |
| Average Operating Power (W) |
3.7W |
| Idle Average (W) |
2.5W |
| Standby Mode/Sleep Mode, Typical (W) |
0.25W |
| Voltage Tolerance (5V) |
±5% |
| Voltage Tolerance (12V) |
±10% |
Environmental/Temperature
|
| Operating (ambient, min °C) |
0°C |
| Operating (drive reported, max °C) 4 |
65°C |
| Nonoperating (ambient, min °C) |
-40°C |
Physical
|
| Height (mm/in, max) |
20.20mm/0.795in |
| Width (mm/in, max) |
101.6mm/4.0in |
| Depth (mm/in, max) |
146.99mm/5.787in |
| Weight (g/lb, typical) |
630g/1.389lb |
| Carton Unit Quantity |
25 |
| Cartons per Pallet/Cartons per Layer |
40/8 |
