| Specification | Details |
|---|---|
| Model | TP-Link SG3428 Omada |
| Ports | 24 Ports: 24x Gigabit Ethernet Ports, 4x SFP Slots |
| PoE Type | No PoE support |
| Management Type | Managed (L2+ Managed Switch) |
| Switching Capacity | 56 Gbps |
| MAC Address Table | 16K entries |
| Data Transfer Rate | 1Gbps for all Ethernet Ports, 1Gbps for SFP Slots |
| SFP Slots | 4x SFP (Gigabit Fiber) |
| VLAN Support | Yes (Supports VLAN 802.1Q) |
| QoS (Quality of Service) | Yes, 802.1p QoS |
| Link Aggregation | Yes, IEEE 802.3ad |
| IGMP Snooping | Yes |
| Jumbo Frame Support | 9K bytes |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q |
| LED Indicators | Power, Link/Activity (per port) |
| Power Input | 100-240V AC, 50/60Hz |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Temperature | -40°C to 70°C |
| Storage Humidity | 5% to 90% non-condensing |
| Dimensions | 17.3 x 11.5 x 1.7 inches (440 x 292 x 43 mm) |
| Weight | 2.25 kg (4.96 lbs) |
| Mounting | Rack-Mountable |
| Safety Certifications | CE, FCC, RoHS |
| Warranty | 2 years |
