| Model |
TP-Link SG3428XMP Omada |
| Ports |
24 Ports: 16x Gigabit Ethernet PoE+ Ports, 8x Gigabit Ethernet PoE++ Ports, 4x 10GE SFP+ Slots |
| PoE Type |
16x PoE+ (Power over Ethernet Plus), 8x PoE++ (Power over Ethernet Plus Plus) |
| Management Type |
Managed (L2+ Managed Switch) |
| Switching Capacity |
288 Gbps |
| MAC Address Table |
32K entries |
| Data Transfer Rate |
1Gbps for all Ethernet Ports, 10Gbps for SFP+ Ports |
| SFP+ Slots |
4x 10GE SFP+ Slots |
| VLAN Support |
Yes (Supports VLAN 802.1Q) |
| QoS (Quality of Service) |
Yes, 802.1p QoS |
| Link Aggregation |
Yes, IEEE 802.3ad |
| IGMP Snooping |
Yes |
| Jumbo Frame Support |
9K bytes |
| Network Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q |
| PoE Power Budget |
370W (Total for all PoE ports) |
| LED Indicators |
Power, Link/Activity (per port) |
| Power Input |
100-240V AC, 50/60Hz |
| Operating Temperature |
0°C to 40°C |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Temperature |
-40°C to 70°C |
| Storage Humidity |
5% to 90% non-condensing |
| Dimensions |
17.3 x 11.5 x 1.7 inches (440 x 292 x 43 mm) |
| Weight |
3.6 kg (7.94 lbs) |
| Mounting |
Rack-Mountable |
| Safety Certifications |
CE, FCC, RoHS |
| Warranty |
2 years |
