ZKTeco SBT2000S Series Price in Muscat, Oman
ZKTeco SBT2000S Series Price in Muscat, Oman
ZKTeco ZKX6550 X-Ray Luggage Inspection Price in Muscat, Oman - Image 1
Click to enlarge

ZKTeco ZKX6550 X-Ray Luggage Inspection Price in Muscat, Oman

SKU: ZKX6550
  • Innovative fingerprint identification
  • Optional video surveillance system
  • Widely usable for carry-on baggage
  • Excellent, ergonomic industrial design

Add to compare
Add to wishlist
19 People watching this product now!

Description

Tunnel Size 660mm (Width) * 510mm (Height)
Speed 0.20m/s
Height of Transmission Belt 710mm
Maximum Load ≤180kg (Adequate distribution)
Wire Resolution ≥40AWG (0.0787mm metal wire)
Space Definition Horizontal Φ1.0mm \ Vertical Φ2.0mm
Penetrate Definition ≥34AWG
Penetration ≥40mm Steel board
Monitor 17inch LED
System Function                                                                                                                                                               High density alarm, Explosive/Drug auxiliary detect, TIP, Luggage counter, System running timer, X-ray emitting timer, System maintainance, Training
Optional Function Video surveillance system, Bidirection scan, Electrical weighing system, Energy saving mode, Ultrasonic rat repellent
Flim Safety                              ASA/ISO1600 standard of film safety

X-ray System

Tube Voltage 150Kv
Cooling Seal oil cooling / 100%
Single Inspection Dosage Rate ≤1.0μ Gy
Radiation Leak Dosage 0.1μ Gy/h(5cm from the surface)

Installation Specification

Package Size 2235mm(Length)×1160mm(Width)×1700mm(Height)
Console Desk Size               830mm(Length) ×800mm(Width) ×1330mm(Height)
Weight 530KG
Power Consumption                              0.6kVA
Noise 53.8dB(A)



Specification

Overview

Brand

ZKTeco
